6 Inch Mixed Flow In-line Duct Fan
| Name: | 6 Inch Mixed Flow In-line Duct Fan |
|---|---|
| SKU: | D150 |
| Type: | Axial Flow Fan |
| Applicable Industries: | Hotels, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factor |
| Electric Current Type: | AC |
| Tags: | inline duct fan mixed flow fan duct fan hydroponics fan grow room fan 1440 rpm dc motor dc klima fan motor test cihaz cooling fan pc brushless dc motor wheelchair micro dc motor dc motor for hydraulic pump |
Product Description
A solution for most kind of ducting ventilation system.
♦ Simple installation, simple maintenance.
♦ Ball bearing motor.
♦ Large air flow.
♦ High Pressure, high efficiency
♦ Duct air pressurization.
♦ 2 Speeds
♦ Stable long service life
♦ Unique Design.
♦ Low cost.
Product Structure
Blower can be taken out just by unscrew two screws with any operation on the duct and spigot connector.
Performance Table
| Model | Power (W) | Air Volume (m³/h) | Static Pressure (Pa) | Noise (dB) | Duct Size (mm) | Applicable Area |
| AM100 | 28/25 | 200/150 | 180/130 | 30/25 | 100 | 8-16 |
| AM125 | 35/30 | 350/300 | 240/120 | 32/30 | 125 | 10-17 |
| AM150 | 50/40 | 500/400 | 300/250 | 35/30 | 150/160 | 18-36 |
| AM200 | 70/60 | 850/700 | 350/280 | 50/45 | 200 | 34-76 |
| AM250 | 170/130 | 1500/1100 | 550/400 | 60/54 | 250 | 42-84 |
| AM315 | 320/230 | 2300/1800 | 700/500 | 66/61 | 315 | 60-120 |
Overall and Installation Dimension
Multi-Application
Easy Installation & Maintenance
Blower can be taken out just by unscrew two screws with any operation on the duct and spigot connector.
Performance Curve
